High-Speed Deep Laser Marker，Affordable CO2 Laser Machine.
CO2 laser marking machine with high marking speed as well as an integrated controller.
Its’ marking speed could acheive 7000mm/s(80 charactors/s).
And the surface of the markers is very clean, beautiful, and without black imprinting.
₨540,000
| Model: | Meenjet Co2 Laser Marking Machine |
| Operating principle: | Adopt laser light working on the materials’s surface to let the surface of marking area evaporate into the dust |
| Material requirements: | Nonmetal stuff. HRC60. |
| Suitable surface of the materials: | Flat, round, fugged |
| Power consumption: | 20W / 30W / 50W Optional |
| Power requirements: | 220 V ± 10% 50Hz ± 1 % |
| Marking area: | 110X110/150X150/175X175/200X200/300X300mm |
| Marking speed: | 0-7000mm/s(80 characters/s) |
| Marking depth: | 0.01-0.03mm(different hardness, different depth) |
| Marking diameter for round materials: | 0.1-500mm |
| Customized book: | YES |
| Wholesale: | YES |
| Net weight: | About 90KGS |
| Gross weight: | Approx 107KGS |
| Delivery time: | Within 2-7 days |
| Working environment: | -10°c to 60°c |
| Package: | Sea-worthy package or air-worthy package in plywood case |
| Model | Working Area | Main Configuration |
|---|---|---|
| MJ-20 | Standard Type: 110*110mm Optional Type: 70mmx70mm, 175mm×175mm 300*300mm | 1. Chinese Top brand Metal Laser Tube, using life over 20000 hours (American Synard Laser source for your choice); 2. High-speed scanning galvanometer with German technology, with fast marking speed and high precision; 3. Singapore lens, with fine focus effect and stable performance. 4. Professional software installed on the touch screen, which specially designed for the online marking. |
| Model: | SF-20/30/60/100 | Cooling Mode | Air Cooling |
| Power: | 20W(30W/60W/100W available) | Marking Speed | 7000mm/s |
| Laser Source | American Synard /CRD/DW | Minumum Line Width | 0.015mm |
| Laser Wavelength | 1064μm | Minumum Character | 0.2mm |
| Field Lens Brands | Singapore Wavelength | Pulse Frequency | 20Khz-60Khz |
| Marking Area: | 110mm*110mm, optional 70mmx70mm, 175mm×175mm 300*300mm | Operating Environment | 5℃-45℃, clean or dust-free |
| Control Card | JZC Brand EZCAD | Power Supply | AC220V+10% /50Hz or 60Hz |
| Operating System | Win XP/7/8/10 (32 bit, 64bit) |
